PLC Recessed DownLight | 4"/6" | 110lm/W | Smooth adjustable | CCT 2700K-6500K | Wattage 5%-100% | Control by LCP Lighting control panel (Matter)
PLC Recessed Downlight + LCP Lighting control panel (Matter)
The LCP Lighting Control Panel(Matter) is not required Neutral wire . Compatible with both new or older properties, not modification to existing home wiring.
Matter-certified-can work together and are compatible with most major smart home platforms.
Voice Control-Hands-free voice control via Alexa, Siri, Google Assistant and other voice assistants.
Remote App Control-Control from remotely with the app, such as Amazon Alexa, Apple Home, Google Home, and SmartThings.
Scheduling & Timer-Set lighting schedules to auto-launch your preferred scenes for effortless daily comfort.
Local Control-Ultra-easy panel suitable for all ages; easily adjust brightness, color temperature and scene modes.
- Wattage: 4":12W | 6": 15W (5-100% Smooth adjustable)
- CCT: 2700K-6500K Smooth adjustable
- Efficiency: 110lm/W
- Input Voltage: 120-277V AC
- Frequency Range: 50/60Hz
- CRI: >80
- PF: >0.9
- THD: <=20%
- 5 Years Warranty
CONSTRUCTION
Durable solid frame, prefabricated paint with matte white finished. Integrated T-Bar mounting clips built in onto the fixture. Easy installation.
ELECTRICAL
Available as 120-277V input.
APPLICATIONS
The lights apply widely in basements, Kitchens, Hallways, bedrooms, bathrooms and so on.
LCP Lighting control panel(Matter)
Matter-Certified
Regardless of brand,all Matter-certified devices can work together. Matter devices can be controlled by most major smart home platforms.
Support Matter over Wi-Fi, seamlessly integrating with Alexa, Google Home, and Apple Home etc for effortless voice, app, and
automated control.
Control the lamp turn on/off, brightness(5%-100%), color temperature(2700K-6500K) and custom lighting mode.
LISTING
ETL
-Size: 4” | 6"
-Wattage: 4”: 12W | 6”: 15W (5%-100% smooth adjustable with LCP Lighting control Panel(Matter))
-CCT: 4500K (2700K-6500K smooth adjustable with LCP Lighting control Panel(Matter))
-Efficiency: 110lm/W
-Input Voltage: 120-277V AC
-Frequency Range: 50/60Hz
-CRI: >80
-PF: >0.9
-THD: <=20%
-Lifetime: 50,000 hours
-Lumens: 1320lm | 1650lm
-Base Type: Spring Install
-Certifications: ETL
-Rating: Suitable for wet location
-Warranty: 5 Years
-Working Temperature: -4°F to 113°F (-20°C to 45°C)
LCP Lighting control panel(Matter)-7Z120-F361WTD1 | 7Z120-F381WTD1 | 7Z120-F3A1WTD1
Wiring：Single Pole
Rating: 120-277V AC 50/60Hz
Control: Touch-Tone | Voice Control | Remote App Control | Scheduling & Timer
Maximum Load: ≤600W/5.1A | ≤800W/6.8A | ≤1000W/8.5A
Wire Wiring: Single Live or Neutral
Dimmensions: 2.94"x4.69"x1.49"
Material: PC(Flame Retrdant Material)
Working Temperature: -20℃~40℃
| Model | Size | Voltage | Wattage (With PLC Smart Switch) | Efficiency | Lumens | CCT (With PLC Smart Switch) | Certifications |
|---|---|---|---|---|---|---|---|
| JL-4EBPLC12LRCT | 4 inch | 120-277v | 12W(5%-100% Adjustable) | 110lm/W | 1320lm | 2700K-6500K (Smooth Adjustable) | ETL |
| JL-DL4-PLC15W-CCT | 6 inch | 120-277v | 15W(5%-100% Adjustable) | 110lm/W | 1650lm | 2700K-6500K (Smooth Adjustable) | ETL |
